Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Accessory Type | Panel Socket |
| Color | Green |
| Connector Size | Standard |
| Connector Type | Fascia |
| For Use With | Type K Thermocouple |
| Housing Color | Green |
| Maximum Operating Temperature | 120 °C |
| Minimum Operating Temperature | -35°C |
| Mounting Type | Nylon Clip |
| Operating Temperature, Maximum | 120 °C |
| Operating Temperature, Minimum | -35°C |
| Shop By | Factory Choice |
| Thermocouple Type | K |
| UPC Code | 5056111962299 |
Overview
Standard & Miniature Connectors
Polarised, glass-filled polyester connectors for use with thermocouples, extension wires and compensating cables, and fully compatible with products of the same type. Available in thermocouple types K, J, T, E, N, R/S, B and copper.
Maximum wire size 0.5mm2
Color coded in accordance with IEC specification
Washers included
External Cable Clamps available
Nylon clip for quick, simple fixing to panel
Panel mounting
Accepts standard round pin plug connectors
